HC500 HC630
|
Product Name:
HC500 HC630
No. :
 |
Specification
|
Model |
|
Unit |
HC-500 |
HC-630 |
|
Travel |
X travel |
mm |
700 |
1050 |
|
Y travel |
mm |
580 |
750 |
|
|
Z travel |
mm |
580 |
900 |
|
|
Spindle nose to table center |
mm |
200-780 |
130-1030 |
|
|
Spindle center to table face |
mm |
120-700 |
120-870 |
|
|
Table |
Working manner |
|
1° |
|
|
Table size |
mm |
500x500 |
630x700 |
|
|
T-slot (wide x number x space) |
mm |
18x5x100 |
18x5x100 |
|
|
Max loading |
kg |
500 |
950 |
|
|
Spindle |
Spindle motor |
kw |
9/11 |
15/22 |
|
Spindle max speed |
rpm |
6000 |
6000 |
|
|
Spindle taper |
No. |
BT50 |
BT50 |
|
|
Accuracy |
Position accuracy |
mm |
±0.01 |
±0.01 |
|
Repeatability positioning |
mm |
±0.006 |
±0.006 |
|
|
ATC |
Tool shank |
|
BT50 |
BT50 |
|
Tool magazine capability |
|
Standard: 24 |
||
|
Others |
Machine weight |
kg |
13500 |
14500 |
